Chemical Industry

  • CS-810 Transmission Spectrophotometer for Detergent Color Measurement

  • CS-810 is designed for measuring the liquid transmission, absorbance, concentration, color and other parameters. In addition to measuring the liquid transmission, the instrument also includes APHA / PtCo (APHA / Platinum) and Gardner color for products such as resins, solvents, acids, perfumes and varnishes; , Saybolt color for gasoline, white oil, kerosene, lubricating oil and paraffin oil. CS-801 can measure the detergent Lab value and delta E value.

    The following are the testing method
    Step 1.Prepare the samples. Colors of the samples on the left are different. However, for the samples on the right, we can not tell the color difference by visual. Firstly, we will test right samples color difference.


    Step 2.Connect the instrument with PC, turn on the instrument and then calibrate it. Open the testing chamber cover.

    Step 3. Put the standard and sample into the testing chamber. After measurement, we can see the Delta E value of the two samples is 0.26.

    Step 4. Follow the above step to measure the left samples color difference. The delta E value is 0.59.

    According to the value on the PC, we can see the Lab and delta E value for the samples directly on the screen. Our instrument will help customer to control the color quality for detergent and improve the production efficiency.

    Hangzhou CHNSpec Technology is mainly focus on color and gloss measurement field. We keep on developing and researching to ensure the stability of our instruments. Our products are widely used in print industry, painting industry, automobile accessories industry, household appliances production industry and other researching organizations. At the same time, we launch new products to enlarge the utility of our products. If any interest or questions about our product, please do not hesitate to contact us: +86 571 86872381 or visit our website :http://www.hzcaipu.com/en/
